    Ir Mid Wave Infrared Gas Detector Long Wave Cooled 25Hz 50Hz

    Ask Lasest Price
    Brand Name : FOVA
    Model Number : YZT-TCQ-07
    Certification : CE;FCC
    Payment Terms : T/T
    Supply Ability : 10000PCS/Month
    Delivery Time : 7-15work days
    • Product Details
    • Company Profile

    Ir Mid Wave Infrared Gas Detector Long Wave Cooled 25Hz 50Hz

    Gas Detectors,Type II superlattice mid-wave infrared small detector, Long Wave Cooled Detectors,

    Long Wave Detectors

    YZT-TCQ-07 Long Wave Cooled Detectors

    Product Features

    Small size118.5 × 63 × 65 mm
    Light Weight≤ 530 g
    High ReliabilityMTTF ≥15000 h
    Split Cooler12W@23℃
    Anti-interference
    Good image uniformity

    Application Areas

    Widely used in remote sensing fields, including geological exploration remote sensing and mineral analysis, etc.

    Widely used in a variety of remote detection platforms, including aircraft, satellites, ships and other detection platforms.


    Technical Parameters

    DetectorDetector TypeMid-wave infrared compact detectors
    Resolution64 0 × 512
    Pixel size15 μm × 15 μm
    Response band7.7 μm ~ 9.3 μm
    Effective pixel rate≥ 99%
    Refrigeration time at room temperature (23°C)< 7mins
    Refrigeration methodLinear Stirling Refrigerator
    F-number2
    Service life (MTTF)15000h
    Video OutputFrame rate2 5Hz / 50Hz / 100Hz/ External sync
    Analog OutputPAL / NTSC
    Digital OutputCameralink (14-bit raw data or 8-bit video data)
    Control performanceImage AdjustmentContrast, brightness, image polarity, shutter correction, background correction, detail enhancement, electronic magnification
    Cross-sectionshow/ Blanking
    Integration timeContinuously adjustable
    Power supplyInput voltageDC 12V ± 1V
    Power consumptionCooling 2 4 W / Steady 1 2 W
    Environmental parametersOperating temperature-40℃ ~ +60℃
    Storage temperature-50℃ ~ +70℃
    Physical propertiessize118.5 mm × 63 mm × 65 mm (without lens)
    weight≤ 5 30 g (without lens)
