Product Description:
| | Index | 2 FV 300 | 2 FV 400 | 2 FV 500 | 2 FV 600 | 2 FV 700 | Unit |
| Structural form | Vertical horizontal rotation | / |
| Mesa material | Stainless steel/aluminum alloy optional | Kg |
| Maximum load weight | 30~50 | 30~50 | 30~50 | 30~60 | 50~70 | Kg(Optional) |
| Table size | Φ300 | Φ400 | Φ500 | Φ600 | Φ700 | mm |
| Mesa flatness | 0.02 | 0.02 | 0.05 | 0.05 | 0.05 | mm |
| Table height | 400 | 540 | 640 | 740 | 840 | mm |
| Rotation accuracy | ±1~3 | ±1~3 | ±1~3 | ±1~3 | ±1~3 | ″(Optional) |
| Angular position range | ±0〜 ±360 | ±0〜 ±360 | ±0〜 ±360 | ±0〜 ±360 | ±0〜 ±360 | ° |
| Angular position accuracy | ±1~3 | ±1~3 | ±1~3 | ±1~3 | ±1~3 | ″(Optional) |
| Angular resolution | 0.0001 | 0.0001 | 0.0001 | 0.0001 | 0.0001 | ° |
| Angular rate range | 0.001〜10000 | 0.001〜4500 | 0.001〜2000 | 0.001〜1500 | 0.001〜1000 | °/s |
| | Angular rate accuracy | ω＜1 1<ω＜10 10 < ω | ω＜1 1<ω＜10 10 < ω | ω＜1 1<ω＜10 10 <ω | ω＜1 1<ω＜10 10 < ω | ω＜1 1<ω＜10 10 <ω | °/s |
| | Speed smoothness | 1 × 10 -3 | 1 × 10 -3 | 1 × 10 -3 | 1 × 10 -3 | 1 × 10 -3 | 1° Average |
| 1 × 10 -4 | 1 × 10 -4 | 1 × 10 -4 | 1 × 10 -4 | 1 × 10 -4 | 10 ° Average |
| 5 × 10 -5 | 5 × 10 -5 | 5 × 10 -5 | 5 × 10 -5 | 5 × 10 -5 | 360 ° Average |
| Maximum angular acceleration | Inner10000 | Inner14500 | Inner13000 | Inner12000 | Inner12000 | |
| Outer 3000 | Outer 2000 | Outer 1000 | Outer 500 | Outer 500 | °/s2 |
| Rocking function | optional | optional | optional | optional | optional | |
| Rate resolution | 0.0001 | 0.0001 | 0.0001 | 0.0001 | 0.0001 | customizable |
| Slip ring number | 10~80 | 10~80 | 10~80 | 10~80 | 10~80 | Optioanl |
| System bandwidth | 5 ~ 1 0 0 Hz | 5~ 80 Hz | 5~ 50 Hz | 5~50 Hz | 5~ 50 Hz | Hz(Optional) |
| Slip-ring voice | 0.03 | 0.03 | 0.03 | 0.03 | 0.03 | V |
| Leakage flux | ±0.5 | ±0.5 | ±0.5 | ±0.5 | ±0.5 | mT |
Applications:
One of the key Product Application Occasions for the FOVA Single Axis Turntable is in military-grade Motion Simulation Platforms. The precise Rate resolution of 0.0001 and Angular resolution of 0.0001 make it perfect for creating realistic motion simulations for training and research purposes. Military organizations and defense contractors can benefit from the accuracy and durability of this turntable in their simulation systems.
Simulation Equipment Distributors can also make use of the FOVA Single Axis Turntable in various scenarios. Whether it's for testing virtual reality systems, automotive simulators, or flight simulators, this turntable provides a stable platform for realistic motion simulation. The Certification of CE/FCC ensures that it meets industry standards for quality and safety.
With a Table size of Φ700, the FOVA Single Axis Turntable offers a spacious surface for different types of equipment and setups. The Maximum load weight of 30/50 allows for the testing of various heavy devices and components. Additionally, the low Leakage flux of <0.5 ensures minimal interference with sensitive equipment.
Customers can benefit from the quick Delivery Time of 20 and the flexible Minimum Order Quantity of 1, making it easy to acquire this turntable for their specific needs. The Supply Ability of 1000PCS/MONTH ensures a steady availability of the product for large-scale projects or orders.
Support and Services:
The Product Technical Support and Services for the Single Axis Turntable product include:
- Installation guidance and support
- Troubleshooting assistance
- Software updates and maintenance
- User manual and documentation access
- Product training and knowledge transfer
Packing and Shipping:
Product: Single Axis Turntable
Description: A versatile turntable for rotating objects in a single axis.
Package Contents:
- Single Axis Turntable
- Power Adapter
- Instruction Manual
Shipping Information:
- Shipping Method: Standard Shipping
- Shipping Cost: Calculated at checkout
- Estimated Delivery: 5-7 business days
